RKI's new SDM-2009 Calibration Station for the GX-2009 is now available with advanced features for charging, calibration, & bump testing. Once you power up the GX-2009 inside the SDM-2009 Calibration Module, the GX-2009's display will indicate whether it's transmitting data, bump testing, calibrating, and it will indicate the results of the bump test or calibration. The SDM-2009 is a versatile maintenance tool that automates the service of a GX-2009 portable gas monitor. This docking station can be used as a stand alone device for charging, calibration and bump testing, with records stored automatically for future upload to a PC via USB flash drive (PC software and flash drive included). Optional gas available: RKI Calibration 4 Gas Mixture Cylinder H2S 25 ppm / CO 50 ppm / isobutane 50 percent LEL / O2 12 percent in N2, 34AL Part# 81-0154RK-04
Key Features:
- Stand-alone station (no PC required)
- Charging
- Calibration
- Bump test
- Save bump test and calibration records
- Bump test and calibration records copy to USB jump drive
- Includes PC software for viewing/archiving bump test and calibration records
Specifications:
- Input power - 12 VDC, NOTE: AC Adapter with 100- 240 VAC, 50/60 Hz, 0.6A input and 12 VDC, 1.2A output provided as standard.
- Environmental conditions: For indoor use only, -10 degrees C to 40 degrees C, below 80 percent relative humidity, non-condensing
- Maximum number of records saved: 200 (stand-alone), unlimited with software
- 3 ports: 1 calibration gas, 1 fresh air and 1 exhaust
Standard Accessories:
- AC adapter
- USB flash drive
- Single Module Data Viewer Software
- SDMGX Docking Station PC Controller Program
- Inlet air filter
- Instruction manual
- 10 ft. long exhaust tube
- (1) 3 ft. long tube for GAS fitting
- 2 T-fittings (for PC controlled configuration only)
- 10 ft. long 3/16 in. tube for GAS manifolding (used for PC controlled configuration only)
- Check valve (used for PC controlled configuration only)
- USB cable, Type A to Type B
Part Number: RKI01-81-SDM2009-02 - Single point calibration station for GX-2009 with AC adaptor, flash drive, USB cable, tubing installation, CD & demand flow regulator
- SKU:
- RKI01-81-SDM2009-02
- Weight:
- 5.00 LBS
- Width:
- 10.00 (in)
- Height:
- 8.00 (in)
- Depth:
- 13.50 (in)
- Shipping:
- Calculated at Checkout
- MPN:
- 81-SDM-2009-02
- Product Weight (lbs.):
- No
