Confined spaces become hazardous areas when exhaust gathers from cars, trucks, buses, tractors, trailers, forklifts, and other fossil fuel burning engines. Exhaust fumes are highly toxic and exposure to the fumes can result in serious health problems, and even death. That is why the CO and NO2 levels must be measured, and when concentrations reach unsafe, unhealthy levels, the areas must be ventilated. Reliable detection can also protect those who work in these areas from accidents like explosion and fire. A number of different gas detection solutions exist to satisfy these needs. Designing a proper gas detection system can be challenging because of the existing variety of applications in parking garages, hospital/ambulance bays, fire or police stations, boiler rooms, commercial kitchens, indoor stadiums, car dealerships, warehouses, loading docks, train stations, airports, and tunnels. The specifics of the design of the structure must determine which specific monitoring system suits the application best.
The Honeywell E3Point
The versatile Honeywell E3Point network gas detector monitors toxic, oxygen and combustible gases in commercial applications. It can be used as a standalone unit with single or dual-gas detection using a remote sensor, or deployed as a network device interoperable with BACnet, Modbus and other Building Automation Systems. The advantage of E3Point is that it is based on the accurate electrochemical and catalytic bead sensor technology that reduces false alarms. Other benefits of using E3Point include flexible operation, cost effectiveness, versatile communication, and advanced sensing technology. The E3Point Gas Monitor has an accuracy of ± 3%. Diagnostic information can be viewed on LCD display. Interchangeable sensors are pre-calibrated and may be easily exchanged.
To network several E3Point gas detectors together, the 301C is a gas detection controller is the device to do the job. With unique zoning and comparison abilities, it can continuously monitor and average multiple sensor readings in different zones. This unit allows for up to 96 hardwired E3Points to be linked together and back to the 301C on just two pairs of wires. To take advantage of wireless networking, the 301W is a two-year maintenance and calibration free gas detector which uses a wireless mesh network to communicate back with the 301C. The 301C can monitor up to 50 wireless transmitters, and datalogging is an option. Ventilation (exhaust fans) and alarm beacons/warning systems are also controlled and activated by the 301C, and should be placed in appropriate locations as required.| Facility | Building Environment | Gases Present (detected by E3Point) |
|---|---|---|
|
Parking Structure | CO, NO2, C3H8 |
|
Loading Dock | CO, NO2, C3H8, H2 |
|
Transport Terminal | CO, NO2, C3H8, CH4 |
|
Golf Cart Maintenance/Battery Charging Area | CO, NO2, CH4, O2, H2 |
|
Maintenance Garage | CO, NO2, C3H8, O2, H2S, H2 |
|
Hospital/Ambulance Bay | CO, NO2, C3H8, O2 |
|
Fire/Police Station | CO, NO2, C3H8, O2, H2, H2S |
|
Car Wash | CO, NO2, C3H8 |
If you have questions or need help finding the right gas detection solution, please feel free to call us at 800-829-9580, or visit us online at pksafety.com.
