RKI GX-6100 Sample Draw with PID 6 Gas Monitor 72-61A_ _X-C
Description
The RKI GX-6100 Sample Draw with PID 6 Gas Monitor simultaneously monitors up to 6 gases—the standard 4 confined space hazards plus 2 additional smart channels for PID, PPM, IR, or super toxic sensors. Measure combustibles in both PPM and volume ranges with one monitor. Built tough for harsh environments, it features a powerful internal sample pump, man-down and panic alarms, LED flashlight, and auto-rotating LCD display. The PID sensor accesses a library of over 600 VOC gases and resists humidity. With IP-67 dust and water resistance, removable rubber boot, and 5 bright LED lights visible from multiple angles, the GX-6100 delivers comprehensive detection when your team needs it most.
Applications: Confined space entry, Hazmat response teams, Arson investigation, Remediation sites, Perimeter monitoring, Leak detection, Landfill monitoring, Wing tank entry
Key Features:
- LEL, O2, H2S, CO, and choice of up to 2 additional toxic/IR gas sensors
- New 4-gas sensors with up to 3-year warranty
- 2 Interchangeable smart sensor slots
- PID library of over 600 VOCs
- Rapid sharing of emergency alerts via Bluetooth
- PPM Leak Check mode
- LEL sensor protection mode
- Man-down alarm
- Panic alarm
- Auto display rotation
- Peak-bar display
- LED Light source
- Internal sample pump
- Light weight, small, rugged IP-67 design
- Interchangeable battery packs (Li-ion / alkaline)
- Operates up to 28 hours on Li-ion battery pack
- Field replaceable sensors, batteries, filters and pump
Included with Monitor:
- Rubber Boot
- Belt Clip
- Hand Strap
- Tapper Nozzle
- Probe with hydrophobic & Dust Filter, 3' Teflon Lined Hose
Remember to calibrate every three months and regularly perform bump tests.
Specification Sheet:
Manual:
FAQ — GX-6000 vs. GX-6100 Comparison:
Part Numbers:
72-61ABIX-C - LEL/O2/H2S/CO/VOCs (0-4,000 ppm PID)/SO2
72-61ABKX-C - LEL/O2/H2S/CO/VOCs (0-4,000 ppm PID)/NO2
72-61ABLX-C - LEL/O2/H2S/CO/VOCs (0-4,000 ppm PID)/HCN
Related Searches
Confined Space,
Gas Detection,
Multi-Gas Monitors,
Portable Gas Monitors And Detectors
Frequently Asked Questions
What gases does the GX-6100 Sample Draw 6-gas monitor detect?
The GX-6100 Sample Draw simultaneously monitors LEL, O2, H2S, and CO as standard, plus two additional smart sensor channels configurable for PID (VOCs), IR, or super toxic sensors such as SO2, NO2, or HCN. Available part numbers cover SO2, NO2, and HCN 6th-channel configurations. Contact PK Safety at
800.829.9580 for custom configurations.
What distinguishes the sample draw version from the standard GX-6100?
The sample draw configuration ships with a probe, 3-foot Teflon-lined hose, and hydrophobic dust filter, allowing technicians to test atmosphere before entering a confined space. The internal pump draws a sample from the space while the worker remains outside. Electrically and mechanically, the monitor is otherwise identical to the 4-gas PID version.
Is the GX-6100 approved for classified hazardous areas?
Yes. The GX-6100 carries ATEX and CSA intrinsic safety certifications and is rated IP-67 for dust and water resistance. The removable rubber boot provides additional impact protection for harsh outdoor environments and industrial facilities.
What is the battery life on the GX-6100 Sample Draw?
A fully charged Li-ion battery pack delivers up to 28 hours of runtime with the internal pump operating. An alkaline battery pack is interchangeable for field situations where charging facilities are unavailable. Battery, sensors, filters, and the pump are all field-replaceable.
Who services the RKI GX-6100?
PK Safety is an RKI Factory Authorized Service Center. We stock replacement sensors, batteries, filters, and pump assemblies for the GX-6100 and can perform warranty and out-of-warranty repairs. Contact us at
800.829.9580 to schedule service.
Read more
Description
